| Kondüktör: | Kalaylı bakır telli | yalıtım: | XLPE |
|---|---|---|---|
| Ceket: | XLPE | Kablo Şekli: | Yuvarlak |
| Başvuru: | Endüstriyel, tüketici elektriği, tıbbi, vb. | Paketleme: | Makaralarda paketlenmiş |
| Volatge: | 600V | Sıcaklık: | 90°C |
| Vurgulamak: | Fixed Multi Core Cables,XLPE Insulation Multi Core Cables,600V Multi Core Cables |
||
Fixed Multi Core Cables TC-ER/600V/90C 3X12AWG [BLACK,WHITE, GREEN] Energy Storage Cable
Product Description
Application: Internal wring or external interconnection of electronic equipment, Energy Storage
Application standard: E476298 (UL) TYPE TC-ER
Product character:
Tensile strength:≥10.3MPa Elongation:≥100%
Aged condition:136±1℃×168h
Percent of original tensile strength: ≥70%
Percent of original elongation: ≥70%
UL758 -E258652-20060111-CertificateofCompliance-1....
| Construction | ||
| Conductor | Bare Copper Stranded | |
| Cross section | 12AWG | |
| Construction | 65/0.254mm | |
| Strand Dia. | 2.36mm | |
| Insulation | XLPE | |
| Nom.Thickness | 0.76mm | |
| Min.Thickness | 0.69mm | |
| Insulation Dia. | 4.00±0.20mm | |
| Insulation colour | 1.black 2.white 3.yellow/green | |
| Material | Non-woven | |
| Assembly | 3C×12AWG | |
| Jacket | XLPE | |
| Nom.Thickness | 1.14mm | |
| Min.Thickness | 0.91mm | |
| O.D. | 11.40±0.40mm | |
| Colour | per request | |
Insulation:XLPE
Conductor : Bare Copper Stranded
Construction
Insulation: 1.black 2.white 3.yellow/green
Jacket :per request
Jacket: XLPE
Application
These cables are appropriate for flexible use with medium mechanical stresses, and free movement without tensile stress or forced movements in dry, moist and wet rooms but not open air. Suitable to be used as measuring and control cables in tool machines,
Standards
International: UL758 , UL1581, UL2464
RoHS,REACH Compliant,
Technical data
Rated voltage:600V
Rated Temperature: 90℃
Voltage withstand test:AC 3.0kV/1min
Properties
Effectively resist electromaganetic interference
Excellent insulation performance
Extensively oil resistant
Flexible
| Electric Performance | |
| Rated Temperature | 90℃ |
| Voltage rating | 600V |
| Max.conductor DC resistance(20℃) | 5.43Ω/km |
| Dielectric Strength AC | 3.0kV/1min |
